Diamond Tile Blade

DUT

Description

DUT Porcelain Diamond Tile Blade for angle grinders and fixed machines to cut porcelain (grade 5), ceramic, natural stone and other very hard tiles. Can be used dry up to 125mm but water is recommended above this dimension.

Size 115mm, 125mm & 150mm are also super thin.

How Diamond Blade Features Work – pdf »

Technical Information »

Use me for…

Porcelain (grade 5) / Ceramic / Natural stone and other very hard tiles. Can be used dry up to 125mm but water is recommended above this dimension.

WITH: Angle Grinders | Table Saws | Petrol Saws  (See size chart below)

Download data sheet for full list of materials that can be cut with the DUT blade.

THE ULTIMATE BLADE FOR THE HARDEST OF PORCELAIN TILES

PORCELAIN GRADE 5 AND ALL OTHER VERY HARD TILES
  • Fast cutting with reduced chipping
  • 10mm rim height
  • Continuous turbo rim- (115 & 125mm)
  • Ventilated core
  • Super thin - (115, 125 & 150mm)
  • Can be used dry up to 125mm only
  • Reinforced flange for stability
  • Turbo rim & narrow gullet (150 to 350mm)
  • Ventilated core
  • Sizes above 125mm are a segmented design (and not a continuous turbo rim)

Sizing Options

Part number Diameter Bore Machine
115DUT 115mm (4½”) 22.23mm Angle Grinders
125DUT 125mm (5″) 22.23mm Angle Grinders
150DUT 150mm (6″) 25.40mm Table Saws
180DUT 180mm (7″) 25.40mm Table Saws
200DUT 200mm (8″) 25.40mm Table Saws
230DUT 230mm (9″) 25.40mm Angle Grinders
250DUT 250mm (10″) 25.40mm Table Saws
300DUT 300mm (12″) 25.40mm Petrol Saws
350DUT 350mm (14″) 25.40mm Petrol Saws

115 & 125 diameter can be used dry

Part number Diameter Bore Machine
180DUT-SCS7* 180mm (7″) 22.23mm SCS7

DRESSING STONE

Aluminium oxide stone for the re-dressing of diamond tile blades – Part No. DRESS-STONE
